ADVENTURE WAITS AT THE NEXT CORNER

Beauty is more than skin deep: the Aim's sleek looks are thanks to its Smooth Welded head tube and seat tube junctions. It incorporates a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance. There's even a flat disc mount that integrates seamlessly with our kickstand mount, and integrated mounting points for ACID mudguards and carrier. Updated geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. Our SizeSplit system has an expanded range, too, so however tall you are there'll be an Aim that fits perfectly.

THE AIM RACE IS THE ADAPTABLE BIKE YOU NEVER KNEW YOU NEEDED, BUT WILL WONDER HOW YOU MANAGED WITHOUT. FROM THE LOCKOUT-EQUIPPED SUSPENSION FORK TO POWERFUL DISC BRAKES, IT'S GOT YOUR BACK ON ANY RIDE FROM THE WEEKDAY COMMUTE TO WEEKEND FORAYS INTO THE GREAT OUTDOORS.

The devil is in the details. At CUBE we know that only too well, which is why the Aim Race's 100mm suspension fork features a lockout – so you can reduce bob and bounce when you're riding hard. With grippy tyres, powerful hydraulic disc brakes and the wide range of Shimano's 2x8 gears, you've all you need to build your own adventure. And, with SizeSplit, there's an Aim Race that'll fit you perfectly.

FRAME

·         FRAME

Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount

·         SIZE
Size Split: 27.5: XS (14"), S (16") // 29: M (18"), L (20"), XL (22"), XXL (24")

SUSPENSION

·         SUSPENSION FORK
SR Suntour XCT Disc, 100mm, Lockout

DRIVETRAIN & BRAKES

·         BRAKE SYSTEM
Clarks Clout 1, Hydr. Disc Brake PM/FM (180/160)

·         REAR DERAILLEUR
Shimano RD-M3020, 8-Speed

·         FRONT DERAILLEUR
Shimano FD-M315, Top Swing, 31.8mm Clamp

·         SHIFTERS
Shimano SL-M315, Rapidfire-Plus

·         BOTTOM BRACKET
Thun Paso-ML, 73mm BSA

·         CRANKSET
Shimano FC-M315, 36x22T, 170mm

·         CASSETTE
Shimano CS-HG31, 11-34T

·         CHAIN
KMC Z8.3

COCKPIT

·         HANDLEBAR
CUBE Rise Trail Bar, 680mm

·         STEM
CUBE Performance Stem Race, 31.8mm

·         GRIPS

ACID React

·         HEADSET
CUBE FPH868, Semi-Integrated

WHEELS

·         FRONT HUB
Shimano HB-TX505, QR, Centerlock

·         REAR HUB
Shimano FH-TX505, QR, Centerlock

·         RIMS
CUBE ZX20, 32H, Disc

·         TYRES
Schwalbe Smart Sam, Active, 2.25

FINISHING KIT

·         SEAT POST
CUBE Performance Post, 27.2mm

·         SADDLE
Natural Fit Venec Lite

·         PEDALS

ACID PP MTB

PRODUCT INFORMATION

·         WEIGHT
14,3 kg

·         COLOUR
black´n´azure
