ADVENTURE WAITS AT THE NEXT CORNER
Beauty is more than skin deep: the Aim's sleek looks are thanks to its Smooth Welded head tube and seat tube junctions. It incorporates a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance. There's even a flat disc mount that integrates seamlessly with our kickstand mount, and integrated mounting points for ACID mudguards and carrier. Updated geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. Our SizeSplit system has an expanded range, too, so however tall you are there'll be an Aim that fits perfectly.
WHERE D'YOU WANT TO GO TODAY? WITH THE AIM PRO'S COMFORTABLE SUSPENSION FORK, GRIPPY TYRES AND STRONG HYDRAULIC DISC BRAKES, THE CHOICE IS YOURS. TAKE THE ROAD LESS TRAVELLED, AND SEE WHERE IT LEADS YOU...
Got an off-road itch that needs scratching? The Aim Pro could be the relief you're looking for. With its grippy tyres and 100mm suspension fork, it's got the comfort and control you'll need to keep riding when you reach the end of the road. Wide-ratio Shimano 2x8 gears will help you see off the steepest climbs, and strong hydraulic brakes put you in control on the descents. Best of all, SizeSplit makes it easy to find the perfect fit for every rider – and the frame is even ready to accept a future dropper post upgrade.
FRAME
· FRAME
Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount
· SIZE
Size Split: 27.5: XS (14"), S (16") // 29: M (18"), L (20"), XL (22"), XXL (24")
SUSPENSION
· SUSPENSION FORK
SR Suntour XCT Disc, 100mm
DRIVETRAIN & BRAKES
· BRAKE SYSTEM
Tektro HD-M275 / TKD-150, Hydr. Disc Brake (160/160)
· REAR DERAILLEUR
Shimano RD-M3020, 8-Speed
· FRONT DERAILLEUR
Shimano FD-M315, Top Swing, 31.8mm Clamp
· SHIFTERS
Shimano SL-M315, Rapidfire-Plus
· BOTTOM BRACKET
Feimin FP-B902N, 73mm BSA
· CRANKSET
Shimano FC-M315, 36x22T, 170mm
· CASSETTE
Shimano CS-HG31, 11-34T
· CHAIN
KMC Z8.3
COCKPIT
· HANDLEBAR
CUBE Rise Trail Bar, 680mm
· STEM
CUBE Performance Stem Pro, 31.8mm
· GRIPS
ACID React
· HEADSET
CUBE FPH868, Semi-Integrated
WHEELS
· FRONT HUB
CUBE Alloy Light, QR, 6-Bolt
· REAR HUB
CUBE Alloy Light, QR, 6-Bolt
· RIMS
CUBE ZX20, 32H, Disc
· TYRES
CUBE IMPAC Smartpac, 2.25
FINISHING KIT
· SEAT POST
CUBE Performance Post, 27.2mm
· SADDLE
Natural Fit Venec Lite
· PEDALS
CUBE PP MTB
PRODUCT INFORMATION
· WEIGHT
14,7 kg
· COLOUR
grey´n´flashyellow
